    7/11/12 Degree Taper Chisel Bit

    Ask Lasest Price
    Brand Name : SANSUNG
    Model Number : Chisel Bit
    Certification : ISO SGS
    Price : USD
    Delivery Time : 20-30 days
    Payment Terms : T/T
    Supply Ability : 2000 PCS/Month
    • Product Details
    • Company Profile

    7/11/12 Degree Taper Chisel Bit

    The taper chisel bit is widely used in drilling holes with a depth size less than 5 meters and diameter scope in 20-45 mm by light-duty hand hold drills, Like Y6, Y10, Y24, , major use in natural dimensional stone quarry for small hole drilling, block ‘s trimming and 2nd splitting for small blocks.

    To match hexagonal 22 mm and hexagonal 12 mm’s tapered drill rod with 4, 6, 7, 11, 12 degree, all tapered chisel bit are made

    with high quality of raw material through special heat treatment.

    Regular Size Specifications:


    Dia.
    mm
    Tip size
    H*W(mm)
    Connection
    d(mm)*a
    Length
    mm
    Product-code
    Suitable
    machines
    20
    10*5
    22*7°
    52
    C122-52
    Y6
    30
    12*8
    22*7°
    80
    C130-80
    Y20, Y24,
    YT24&YT28
    32
    12*8
    22*7°
    80
    C132-80
    34
    12*10
    22*7°
    80
    C134-80
    36
    15*10
    22*7°
    80
    C136-80
    38
    15*10
    22*7°
    80
    C138-80
    40
    15*10
    22*7°
    80
    C140-80



    We also supply: taper button bit, taper drill rod, integral drill rod, thread button bit, extension rod/MF rod, etc.
