R25 R32 T38 T45 T51 35mm-152mm Thread Button Bit

Xiamen Sansung Imp. & Exp. Co., Ltd
Contact Now
    Buy cheap R25 R32 T38 T45 T51 35mm-152mm Thread Button Bit from wholesalers

    Buy cheap R25 R32 T38 T45 T51 35mm-152mm Thread Button Bit from wholesalers
    • Buy cheap R25 R32 T38 T45 T51 35mm-152mm Thread Button Bit from wholesalers

    R25 R32 T38 T45 T51 35mm-152mm Thread Button Bit

    Ask Lasest Price
    Brand Name : SANSUNG
    Model Number : R32 T38 T45 T51
    Certification : ISO SGS
    Price : US$0/pc
    Delivery Time : 20 days
    Payment Terms : T/T
    Supply Ability : 200 PCS per week
    • Product Details
    • Company Profile

    R25 R32 T38 T45 T51 35mm-152mm Thread Button Bit

    Same as taper button bits, thread button bits are most popular drill bits in the world now.

    It is suitable for powerful percussive drills and top hammers with high speed drifter, such as Atlas Copco 282 rocket boomer,

    Atlas Copco 352 rocket boomer jumbo, Atlas Copco D7 roc, Furukawa HCR 1200, Tamrock, and Ingesoll Rand ECM660, and

    widely used in bench and production drilling, extensional drilling.

    Our thread button bit are made of high quality alloy steel bar and tungsten carbides, through heat treatment so that it can

    withstand the toughest rock drilling demands, and transmit intensive impact energy into the rock with the least possible loss

    of energy.

    Thread
    Bit Dia.( mm)
    Bit face
    shape
    Button
    shape
    Flash
    hole No.
    Button
    No.
    Button
    size(mm)
    R25
    35-45
    On request
    spherical, ballistic, conical
    1/2
    6-8
    7-11
    R32
    41-51
    On request
    spherical, ballistic, conical
    1/2
    6-9
    8-11
    R38
    64-89
    On request
    spherical, ballistic, conical
    1/2
    9-14
    10-12
    T38
    57-102
    On request
    spherical, ballistic, conical
    1/2
    9-14
    10-14
    T45
    70-115
    On request
    spherical, ballistic, conical
    1/2
    12-16
    10-14
    T51
    89-127
    On request
    spherical, ballistic, conical
    1/2/3
    10-20
    11-16
    ST58
    89-152
    On request
    spherical, ballistic, conical
    2/3/4
    13-21
    12-16
    GT60
    89-152
    On request
    spherical, ballistic, conical
    2/3/4
    13-22
    12-18
